Curved 500×1000 Rental LED Screen Panel 1000C4 Series P1.953 P2.604 P2.976 P3.91 P4.81
1180-4

LED Display 500×1000 Curved Professional Rental LED Screen P1.5625 P1.953 P2.604 P2.976 P3.91 P4.81 Series

LM1000C4 Series  has two quick lock devices on the left and right sides, which can ensure faster assembly speed and better screen flatness.
It also has anti-collision feet at the bottom of the cabinet to protect the edge of the LED module.
LM500C4 and LM1000C4 Can be installed together up and down , left and right.

1000C4-2

Quick Install

LM1000C4 series P1.9 Indoor Outdoor LED Display 500×1000 Two Fast Locks on Left and Right Side, Ensure faster assembly and better screen flatness.

EA1000C4-2-1

High Precision Curve Lock

High Precision Curve Lock design P1.5625 LED Display 500×1000 is adopted to solve the problem that the old curved lock is difficult to use before.
Rotational control, more accurate, easy to use and quickly adjust curve degree.

1000C4-3

Curved Installation Support

LM1000C4 series P2.9 Curved LED display rental can be installed in inner arc or outer arc.

EA1000C4-4-1

Free Splicing

LM500C4 series and LM1000C4 series can be installed together up and down, left and right.

5-6

Corner Protector for LED

LM1000C4 series P2.6 Rental LED sign has four corner protectors in each corner to prevent LED to be damaged,
more security for transport, installation, operation, assemble & disassemble foldable design, and easy to use.

56556

Lightweight and Thin

LM1000C4 series P3.9 Waterproof LED display rental cabinet weighs 13KG/pc, easy to operate: one person to install, disassemble and maintain.

1000C4-7

IP65 Dustproof And Waterproof

The LM1000C4 series outdoor LED display 500×1000 supports IP65 dustproof and waterproof,
it can resists severe weather conditions during outdoor activities. And die-cast aluminum is corrosion resistant.

1000C4-4

Wide Viewing Angle

Viewing angle is up to 140° vertical and horizontal, providing a wide viewing angle.
Ultra-wide viewing angle give you the largest screen viewing area. It offers you clear and natural images in all directions.

1000C4-9Professional

Outdoor Rental Curved LED Display 500x1000 Series Parameter

Pixel Pitch (mm)P2.6P2.97P3.91P4.81
ModelLM1000C4-P2.6LM1000C4-P2.97ELM000C4-P3.91LM1000C4-P4.81
Pixel ConfigurationSMD1415SMD1415SMD1921SMD1921
Density (Pixels/㎡)147,928112,89665,53643,264
Module Resolution (Pixel)96x9684x8464x6452x52
Module Size (mm) 250x250250x250250x250250x250
Driving Mode (Duty) 1/211/21 1/161/13
Cabinet Size (mm) 500x1000500x1000500x1000500x1000
Cabinet Weight (KG) 13131313
Brightness (CD/㎡) ≥6,000≥6,000≥6,000≥6,000
Viewing Angle (°) 140140140140
Gray Grade (Bits) 14141414
Operation Power AC100-240V 50-60HzAC100-240V 50-60HzAC100-240V 50-60HzAC100-240V 50-60Hz
Max. Power Consumption (W/㎡) 720720720560
Avg. Power Consumption (W/㎡) 240240240190
Frame Frequency (Hz) ≥60≥60≥60≥60
Refresh Frequency (Hz) ≥3,840≥3,840≥3,840≥3,840
Working Temperature (ºC) -20~+60-20~+60-20~+60-20~+60
Lifetime (Hours) 100,000100,000100,000100,000
Protection Grade IP65(front), IP54(rear)IP65(front), IP54(rear)IP65(front), IP54(rear)IP65(front), IP54(rear)

Indoor Curved Rental LED Display 1000X500 Series Parameter

Pixel Pitch (mm)P1.95P2.5P2.6P2.97P3.91P4.81
ModelLM1000C4-P1.95LM1000C4-P2.5LM1000C4-P2.6LM1000C4-P2.97LM1000C4-P3.91LM1000C4-P4.81
Pixel ConfigurationSMD1515SMD1515SMD1515SMD2121SMD2121SMD2121
Density (Pixels/㎡)262,144160,000147,928112,89665,53643,264
Module Resolution (Pixel)128x128100x10096x9684x8464x6452x52
Module Size (mm)250x250250x250250x250250x250250x250250x250
Driving Mode (Duty) 1/32 1/25 1/32 1/281/161/13
Cabinet Size (mm)500x1000500x1000500x1000500x1000500x1000500x1000
Cabinet Weight (KG)121212121212
Brightness (CD/㎡)≥1000≥1000≥1200≥1,000≥1,200≥1,000
Viewing Angle (°)140140140140140140
Gray Grade (Bits)141414141414
Operation PowerAC100-240V 50-60HzAC100-240V 50-60HzAC100-240V 50-60HzAC100-240V 50-60HzAC100-240V 50-60HzAC100-240V 50-60Hz
Max. Power Consumption (W/㎡)480480480480576560
Avg. Power Consumption (W/㎡)160160160160192190
Frame Frequency (Hz) ≥60 ≥60 ≥60≥60≥60≥60
Refresh Frequency (Hz) ≥3,840 ≥3,840 ≥3,840≥3,840≥3,840≥3,840
Working Temperature (ºC)-20~+60-20~+60-20~+60-20~+60-20~+60-20~+60
Lifetime (Hours)100,000100,000100,000100,000100,000100,000
Protection GradeIP31IP31IP31IP31IP31IP31
