Novastar VX6S All-in-one Controller Specification
Description

Novastar VX6S All-in-one Controller Specification
Inputs: 2 × 3G-SDI, 2 × HDMI1.3, 2 × DVI, 1 × USB
Outputs: Ethernet port × 6
Maximum pixel CLK is 165MHz
Video Loop: DVI LOOP, SDI LOOP
Video Monitor: VGA OUT, DVI OUT
Communication Mode: USB/LAN
Image Mosaic, Crop Settings, PIP
Power: Emerson power supply
Certification: CE, ROHS, FCC, UL, EAC

The Novastar VX6S video controller is an all-in-one video controller that integrates 6 gigabit ethernet sending outputs, Capacity: 3.9 Million, Width & Height Max: 4096 pxels.

The VX6S nova video processor is designed with powerful video processing, 3 layers and seamless switching functionality, switching and transmission capabilities, novastar vx6s specs is needful.



Novastar VX6S All-in-one Controller Specification

• 7 input connectors: 2× 3G-SDI, 2× HDMI1.3, 2× DVI, and 1× USB
• Supports 3× layers and 1× OSD
• Supports quick and advanced screen configurations
• Switches the PVW to PGM
• Supports PGM preview in the switcher mode
• Supports input resolution adjustment and input source backup
• Supports screen brightness adjustment
• Multiple VX6s units can be cascaded
• Automatically scales the image to fit the whole screen
• The maximum video output width is 4096 pixels
• 16 user presets can be created and saved as templates
• Intuitive OLED screen and clear button indicator lights
• Any HDMI or DVI input can be used for vertical output sync
