5 years warranty / 7000 -10,000 nits super high brightness / IP66 water-proof
no need ventilation & air conditioning system
Platinum LED Display Leeman IP66 outdoor LED Display Screen is new genration of outdoor fix installation LED display. High brightness 7000-9000 nits, 150w per square meter average power consumption, no need any ventilation or aircondition system
Outdoor Fixed Screen suppliers and factory,Custom Platinum Series Outdoor Fixed DOOH LED Display Aluminum die-casting LED module housing for IP68 rating protection and natural cooling without any ventilation and aircon
7000 – 10,000 nits high brightness,1:5000 contrast ratio
average 120-150W energy-saving power consumption
IP66 front and back high protection cabinet
Super light weight die-casting magnesium cabinet, 28-32kg per cabinet
Water-proof protection of power supply and receiving card inside the cabinet
Heat resistant,fireproof, insulation of cables
IP66 front and back high protection cabinet
Super light weight die-casting magnesium cabinet, 28-32kg per cabinet
| Pixel Pitch mm | P6.67 | P8 | P10 |
|---|---|---|---|
| Pixel Matrix Per SQM | 22500 | 15625 | 10000 |
| Pixel Configuration | SMD 2727 | SMD3535 | SMD3535 |
| Power Con.(Max/Avg) | 550/200 w/sq.m | 550/190 w/sq.m | 550/190 w/sq.m |
| 480mm x 320mm | 480mm x 320mmv | 480mm x 320mm | |
| Modules Resolution | 72 x 48 | 60 x 40 | 48 x 32 |
| 960mm x 960mm x 75mm(W x H x D) | 960mm x 960mm x 75mm(W x H x D) | 960mm x 960mm x 75mm(W x H x D) | |
| Cabinet Resolution | 144 x 144 | 120 x 120 | 96 x96 |
| Cabinets Weight(kg) | 28kg /61.72lbs | 28kg /61.72lbs | 28kg /61.72lbs |
| Serivice Access | Front & Rear | ||
| Gray Scale(bit) | 16 | ||
| IP Rate | IP66 | ||
| Input Voltage(AC) | 110V / 240V 50/60 HZ | ||
| Lifespan(hrs) | >100,000(hrs) |
