Rolling LED Screen For Floor Dance – Rental Liftable and Foldable Portable LED Display Kit
360° foldable Smart Plus Rolling LED Dance Screen
High quality and IP65 rating with waterproof grout for outdoor indoor use
Hanging installation or magnet-based mounting
Discrete power supply
Easy installation without panels, steel structure and fans
Slim and light display for efficient and convenient transportation and installation
Remote control is optional for one-touch automatic lifting and lowering
P0.7 P1.25 P1.56 P1.953 P2.604 P3.91 GOB Rolling LED Screen Foldable LED Display Parameters
| Item | GOB-P1.25 | GOB-P1.56 | GOB-P1.953 | GOB-P2.604 | GOB-P3.91 |
| LED | NationStar SMD1010 | NationStar SMD1010 | NationStar SMD1010 | NationStar SMD1515 | NationStar SMD2121 |
| Pixel Pitch | 1.25mm | 1.5625mm | 1.953mm | 2.604mm | 3.91mm |
| LED Module Size (mm) | W500 x H62.5 x D14mm | ||||
| LED Module resolution (pixels) | 400 x 50 pixels | 320 x 40 pixels | 256 x 32 pixels | 192 x 24 pixels | 128 x 16 pixels |
| Signal processing capabilities | 14-16 bit | 14-16 bit | 14-16 bit | 14-16 bit | 14-16 bit |
| Grayscale grade | 4096-65536 | 4096-65536 | 4096-65536 | 4096-65536 | 4096-65536 |
| Refresh Rate（Hz） | ≥3840 Hz | ≥3840 Hz | ≥3840 Hz | ≥3840 Hz | ≥3840 Hz |
| Scanning Method | 1/50 | 1/40 | 1/32 | 1/24 | 1/16 |
| Brightness | >800cd/m2 | >800cd/m2 | >800cd/m2 | >900cd/m2 | >1000cd/m2 |
| Best viewing distance (meter) | ≥ 1.2m | ≥ 1.5m | ≥ 1.9m | ≥ 2.6m | ≥ 3.9m |
| Weight | 16kg/㎡ | 16kg/㎡ | 16kg/㎡ | 16kg/㎡ | 16kg/㎡ |
| Viewing angle（°） | 140° | 140° | 140° | 140° | 140° |
| Input voltage（V） | DC 24V | DC 24V | DC 24V | DC 24V | DC 24V |
| Maximum power consumption | 512w/sqm | 512w/sqm | 512w/sqm | 512w/sqm | 512w/sqm |
| Average power consumption | 170w/sqm | 170w/sqm | 170w/sqm | 170w/sqm | 170w/sqm |
| Temperature | -20 ℃/+50℃ (working) | -20 ℃/+50℃ (working) | -20 ℃/+50℃ (working) | -20 ℃/+50℃ (working) | -20 ℃/+50℃ (working) |
| ‐40 ℃/ +60℃ (storage) | ‐40 ℃/ +60℃ (storage) | ‐40 ℃/ +60℃ (storage) | ‐40 ℃/ +60℃ (storage) | ‐40 ℃/ +60℃ (storage) | |
| Protection level | IP 65 / IP 41 | IP 65 / IP 41 | IP 65 / IP 41 | IP 65 / IP 41 | IP 65 / IP 41 |
| Humidity | 10%~90% (working) | 10%~90% (working) | 10%~90% (working) | 10%~90% (working) | 10%~90% (working) |
| 10%~90% (storage) | 10%~90% (storage) | 10%~90% (storage) | 10%~90% (storage) | 10%~90% (storage) | |
| Lifetime（hours） | 100000 | 100000 | 100000 | ≥100,000 | ≥100,000 |
| Maintenance method | Rear | Rear | Rear | Rear | Rear |
| NovaStar Control System | A5S PLUS | A5S PLUS | A5S PLUS | A5S PLUS | A5S PLUS |
