IP65 Sharpy Beam 20R 480W Moving Head Waterproof Light
600W 480W BEAM Moving Head Light IP65 Waterproof Outdoor events stage lighting, High Power Beam Moving Head Light 480W Beam Dmx512 Led Sharpy Disco Dj Stage Lights, 700W LED Waterproof Moving Head light(3in1) · 480W Waterproof Beam Light (700W) · 550W Waterproof Beam Light (Rocket Version) · Waterproof 300W LED Moving Light
LIGHT SOURCE
● Light Source: Original Customized PHILIPS lamp(7500K~8500K)
● Ballast: Original Customized PHILIPS
● Average Life Span: ≥1500hours
POWER
● Input Voltage: AC90~240V, 50/60Hz
● Power Consumption: 500W/600W/800W
OPTICAL SYSTEM
● Luminous Flux: 660000lumen@10m
● Beam Angle: 0~1.2°
● CRI: 85±5
● PFC: ≥0.95
● Focus: Motorized linear focus
● 1 Prism Wheel: 1pc 8-facet prism, bidirectionally rotating at variable speed (3-facet or 16-facet prism is optional)
● Frost: 1pc frost filter, can achieve soft light effect
● Dimmer: 0~100% mechanical dimming, smooth without flicker
● Shutter/Strobe: Independently strobe with double motors, 0.5~20 F.P.S, speed adjustable
● Lens: Use imported multilayer coating lens combination, the diameter of beam aperture is up to 200mm
● Projection Distance: Over 3000m in similar parallel light
MOVEMENT
● Pan and Tilt: Use high precision 3-phase motors for pan and tilt, accurate location, smoothly moving, automatic correction location
● Pan: 540°rotation, 8/16Bit adjustment
● Tilt: 270°rotation, 8/16Bit adjustment
COLOR SYSTEM
● 1 Color Wheel: Use Taiwan high temperature color filters, 11pcs colors+open, half color and rainbow effect
● 1 Rainbow Wheel: Use Taiwan filters, can project 1 or 8 beams of rainbow effect
GOBOS
● 1 Fixed Gobo Wheel: 14pcs fixed metal gobos+open, bidirectionally shaking & flowing at variable speed
CONTROL
● Control Mode: DMX512, RDM function(remotely set the address code via a large DMX512 controller), Auto Run, Sound Control, MasterSlave and Manual
● DMX Channels: 14/18CH
● Lamp Control: Control the lamp on/off via controller
PHYSICAL
● IP Grade: IP65
● DMX Connector: 3-pin waterproof signal in and out XLR
● Display: 2.8 inch colorful LCD screen, 180° inversion
● Power Cable: Waterproof power cable
MATERIAL
● Fixture Material: High hardness heat dissipation aluminum profile(die-casting aluminium), flame-retardant anti-aging high temperature engineering PVC, use outdoor imported fine sand spraying technology, anti-uv treatment, anti-aging, high temperature, long service life
COOLING SYSTEM
● Cooling System: Use Japan fans, the chip controls the fan speed, the original heat dissipation structure, cooperate with the radiator shell, guarantee the long time outdoor use
FEATURE
● Feature: It can be programmed independently via LCD display, master and slave lights are running synchronously without controller operation
WEIGHT & DIMENSION
● Fixture N.W.: 32.5Kg
● Carton G.W.: 35.5Kg
● Flight Case G.W.: 55Kg
● Fixture Dimension: L434*W400*H756(mm)
● Carton Dimension: L565*W490*H910(mm)
● Flight Case Dimension: L550*W480*H970(mm)
